Double Shaft Shredder

Double Shaft Tire Shredder

Double Shaft Tire Shredder

    The HC Double shaft tire shredder is designed to shred the waste tire for tire recycling. The HC double shaft tire shredder can be used in primary shredding and secondary shredding.

Inquiry Now
  • Features
  • Specification

Main Components:


Rotating screen for double shaft shreddersRotating screen:

The rotating screen can be installed on the double shaft secondary shredder to control the output size. The rotating trommel screen around the shredder body makes the shredded oversize particle back into the shredder hopper to be shredded again.



Bearing Seat:

bearing seat for double shaft shredder

Engineering strengthened design and split two-piece structure achieve convenient maintenance. The dust-proof clapboard prevents the liquid or debris from damaging the bearing seat so that service life of the bearing seat can be prolonged.




Double Shaft Cutters:

Various cutters configurations to suit different applications:

primary shredder cutters

secondary shredder cutters


double shaft for double shaft shreddersMain shaft:

The reducer and the cutters are connected with the main shaft through Germany standard spline with large transmission torque. The parts in the main shaft are not relative sliding. The total contact area with many teeth is able to bear heavy load with high positioning accuracy and even contacting pressure.




PLC Control System:

PLC control system for primary shredderPLC control system for pre-shredder

Start, rotate reversely and stop automatically and remote controllable;

Motor protection when jamming, overloading, overheating and short circuit;

Electronic components are from international famous brand of Siemens, ABB, and Schneider;

Frequency is adjustable to adjust the rotating speed of blades according to the real production capacity to save energy.

Model Parameters:

Customized double shaft tire shredders are supplied to our customers according to specific feeding materials, capacity and output size and so on.

Overall dimensions of double shaft shredders

Small double shaft shredder model parameters

Medium double shaft shredder model parameters

Heavy duty double shaft shredder model parameters
