API 594 Flanged Non Slam CW6MC Tilting Disc Check Valve

API 594 Flanged Non Slam CW6MC Tilting Disc Check Valve

    The SV API 594 tilting disc non slam check valve is designed to solve the problems of water hammer and huge impact on seat when swing check valve and lift type check valve working so that there is no slam and noise when operating.

Inquiry Now
  • Features
  • Specification

  • The SV tilting disc check valve has double eccentric disc design;
  • When close the SV tilting disc check valve, the disc falls on the seat gradually to achieve non slam and noise;
  • Excellent seal performance duo to flexible metal seat;
  • Butterfly type disc, easy to open or close, long service life;
  • Tilting disc structure makes the flow passageway streamline with small flow resistance.

Product range:

  • Size: DN50DN800, 2’’ 32’’
  • Pressure rating: PN16PN100, 150lbs600lbs
  • End connection: Flanged RF, BW
  • Body materials: WCB, WCC, LCB, LCC, WC1, WC6, WC9, C5, C12, C12A, CF8, CF3, CF8M, CF8C, CF3M, 4A, 5A etc.

Technical standards:

  • Design: API 594, DIN3356
  • Face to Face: ASME B16.10, DIN3202
  • Flanged ends: ASME B16.5, ASME B16.47, EN 1092
  • BW ends: ASME B16.25, ASME B31.8, EN12627
  • Test and inspection: API 598, DIN3230, EN12266
