1500#BW 10'' Gear Operated C12A Gate Valves

1500#BW 10'' Gear Operated C12A Gate Valves
    The YFL 1500#BW 10'' Gear Operated C12A Gate Valves is produced in materials of C12A with pressure seal bonnet and welded With pipes suitable for high pressure and high temperature applications in power plants.
Inquiry Now
  • Features
  • Specification

Features:



1. Pressure seal bonnet for high pressure

2. High temperature resistant steel C12A for high temperature





Standards:



Design: API 600, DIN3352, BS1414, BS EN1984

Face to Face: ASME B16.10, DIN3202

Flanged ends: ASME B16.5, ASME B16.47, EN 1092-1

BW ends: ASME B16.25, ASME B31.8, EN12627



Ranges:



Size: DN50DN1200, 2''48''

Pressure rating: PN160PN420, 900lbs2500lbs

End connection: Flanged RF BW

Body materials:  WC6, WC9, C5, C12, C12A etc.

Operation: handwheel, gear operated, electric operated
