PN16 DN50 CF8 Body FEP Lined Plug Valve

PN16 DN50 CF8 Body FEP Lined Plug Valve
    The YFL CF8 Body FEP Lined Plug Valve has CF8 body and FEP Lined to be suitable for corrosive service in Chemical, Oil & Gas etc.
Inquiry Now
  • Features
  • Specification

Product range:

Size: 2"26", DN50DN650

Pressure rating: Class 150lbs2500lbs, PN16PN420

End connection: RF/RTJ/BW

Body materials: WCB/WC6/CF8/CF8M/CF3/CF3M+FEP/PTFE/PFA Lined

Plug materials: CA15/F6a/CF8/CF8M/CF3/CF3M+FEP/PTFE/PFA Lined

Sleeve: PTFE/PPL

Operation: Bare stem/Wrench/Gear/Electric/Pneumatic

Technical standards:

Design: API 599/API 6D

Face to Face: ASME B16.10/DIN3202 F1

BW ends: ASME B16.25/ASME B31.8

Flanged ends: ASME B16.5/DIN2543-2549

Test and inspection: API 598/DIN3230/Spark test

Pressure and temperature rating: ASME B16.34
