1500LBS 10'' PSB High Temperature C12A Gate Valve

1500LBS 10'' PSB High Temperature C12A Gate Valve

The YFL 1500LBS 10'' PSB High Temperature C12A Gate Valve is produced in materials of C12A with pressure seal bonnet suitable for high pressure and high temperature applications in power plants.

Inquiry Now

Features
Specification

Features:

1. Pressure seal bonnet for high pressure

2. High temperature resistant steel C12A for high temperature

Standards:

Design: API 600, DIN3352, BS1414, BS EN1984

Face to Face: ASME B16.10, DIN3202

Flanged ends: ASME B16.5, ASME B16.47, EN 1092-1

BW ends: ASME B16.25, ASME B31.8, EN12627

Ranges:

Size: DN 50～DN1200, 2''～48''

Pressure rating: PN160～PN420, 900lbs～2500lbs

End connection: Flanged RF BW

Body materials: WC6, WC9, C5, C12, C12A, CF8, CF3, CF8M, CF8C, CF3M, 4A, 5A etc.

Operation: handwheel, gear operated, electric operated
